CNC Alu HopUp Kammer MGW - MTW M4
Aluminum CNC MGW - PRO Hop-Up chamber
The highest quality Hop-Up chamber designed for tuning MTW/MTW-9 airsoft rifles.
*The Enchanced version of the chamber features an improved pressure system, thanks to an additional O-ring added to the pressure frame of the spacer. Another significant change is the addition of shims to the adapter, allowing you to adjust the pressure of the chamber to the face of the gearbox.
Rotational chambers by Maxx Model Products are dedicated to the most demanding players, offering unprecedented precision performance and perfect operation of the HU system in the replica.
Chamber features:
- precisely manufactured from a block of aircraft aluminium using CNC technology
- assured compatibility and tightness with replica carbines HPA MTW Milspec, Forged, Billet and MTW-9 series
- rotary adjustment knob
- redesigned precision HopUp and Bucking Nubs 4mm levers (6mm versions are optional), providing problematic operation with standard and R-hop elastics
- removable steel Pivot Pin for set-up and maintenance
- works with M4 standard nozzles from MTW HPA motors
- full compatibility with most soft and hard HU elastics on the market, with zero FPS drop and ball drop
- equipped with a special CNC Delrin Locking C-Clip, preventing vibration and barrel movement
- equipped with 2 compression springs at the top and centre of the chamber, ensuring perfect and secure seating in the replica
- fitted with Inlet Adaptor 11mm to the gearbox (11.5 and 12mm versions available separately) to ensure the nozzle sits centrally in the chamber and reduce wobble
- added, interchangeable brass side wings for improved chamber fit in the outer barrel
- option to fit a ball light module (not included)
Specification:
Length: 51.15mm
Height: 22mm
Inlet Adaptor Outer Diameter (to gearbox): 11mm
Hub Outer Diameter (to outer barrel): 12mm
Hub Inner Diameter (to nozzle): 8mm
Make: Aluminum 6061
Included:
1 x CNC chamber
2 x CNC clear vinyl cover
2 x CNC brass side wing 2.6mm
1 x CNC steel Pivot Pin
1 x CNC aluminium HopUp arm
1 x CNC aluminium Soft Round Nub
1 x CNC aluminium Soft Flat Nub (4mm)
1 x CNC aluminium Hard Concave Nub CNC (4mm)
3 x steel Nub Spring
1 x steel spring guide CNC
1 x steel upper compression spring
1 x steel central compression spring
1 x Delrin Locking C-CNC Clip
1 x CNC Brass Barrel Spacer
1 x Brass Spacer Holder Oring
1 x CNC Aluminum Adjustment Knob
1 x CNC Aluminum Inlet Adaptor (11mm)
5 x Shim 0,1mm
4 x O-ring
